docker基础使用
·
基础篇
docker安装，卸载
一步安装
yum install -y yum-utils device-mapper-persistent-data lvm2 \
&& yum-config-manager --add-repo http://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo \
&& yum makecache \
&& yum -y install docker-ce \
&& mkdir -p /etc/docker/ \
&& echo -e '{\n "registry-mirrors": ["https://x3n9jrcg.mirror.aliyuncs.com"]\n}' > /etc/docker/daemon.json \
&& systemctl daemon-reload && systemctl start docker && systemctl enable docker
-
卸载旧版本(没有可跳过)
-
需要的安装包
yum install -y yum-utils
- 设置镜像仓库（使用阿里云）
yum-config-manager --add-repo \
http://download.docker.com/linux/centos/docker-ce.repo #外国网站
yum-config-manager --add-repo \
http://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo #阿里云
Loaded plugins: fastestmirror
adding repo from: http://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo
grabbing file http://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo to /etc/yum.repos.d/docker-ce.repo
repo saved to /etc/yum.repos.d/docker-ce.repo
- 新软件包的索引
yum makecache fast
Loaded plugins: fastestmirror
Loading mirror speeds from cached hostfile
* base: mirrors.163.com
* extras: mirrors.ustc.edu.cn
* updates: mirrors.ustc.edu.cn
base | 3.6 kB 00:00:00
docker-ce-stable | 3.5 kB 00:00:00
extras | 2.9 kB 00:00:00
updates | 2.9 kB 00:00:00
(1/2): docker-ce-stable/7/x86_64/updateinfo | 55 B 00:00:00
(2/2): docker-ce-stable/7/x86_64/primary_db | 76 kB 00:00:00
Metadata Cache Created
- 安装docker docker-ce(社区版）
yum install docker-ce docker-ce-cli containerd.io
Dependency Updated:
audit.x86_64 0:2.8.5-4.el7 audit-libs.x86_64 0:2.8.5-4.el7
libselinux.x86_64 0:2.5-15.el7 libselinux-python.x86_64 0:2.5-15.el7
libselinux-utils.x86_64 0:2.5-15.el7 libsemanage.x86_64 0:2.5-14.el7
libsepol.x86_64 0:2.5-10.el7 policycoreutils.x86_64 0:2.5-34.el7
selinux-policy.noarch 0:3.13.1-268.el7_9.2 selinux-policy-targeted.noarch 0:3.13.1-268.el7_9.2
Complete!
- 启动docker
systemctl start docker
- 使用docker version确保安装成功
docker version
Client: Docker Engine - Community
Version: 20.10.15
API version: 1.41
Go version: go1.17.9
Git commit: fd82621
Built: Thu May 5 13:16:58 2022
OS/Arch: linux/amd64
Context: default
Experimental: true
Server: Docker Engine - Community
Engine:
Version: 20.10.15
API version: 1.41 (minimum version 1.12)
Go version: go1.17.9
Git commit: 4433bf6
Built: Thu May 5 13:15:18 2022
OS/Arch: linux/amd64
Experimental: false
containerd:
Version: 1.6.4
GitCommit: 212e8b6fa2f44b9c21b2798135fc6fb7c53efc16
runc:
Version: 1.1.1
GitCommit: v1.1.1-0-g52de29d
docker-init:
Version: 0.19.0
GitCommit: de40ad0
- 启动hallo-world
docker run hello-world
Unable to find image 'hello-world:latest' locally
latest: Pulling from library/hello-world
2db29710123e: Pull complete
Digest: sha256:10d7d58d5ebd2a652f4d93fdd86da8f265f5318c6a73cc5b6a9798ff6d2b2e67
Status: Downloaded newer image for hello-world:latest
Hello from Docker!
This message shows that your installation appears to be working correctly.
To generate this message, Docker took the following steps:
1. The Docker client contacted the Docker daemon.
2. The Docker daemon pulled the "hello-world" image from the Docker Hub.
(amd64)
3. The Docker daemon created a new container from that image which runs the
executable that produces the output you are currently reading.
4. The Docker daemon streamed that output to the Docker client, which sent it
to your terminal.
To try something more ambitious, you can run an Ubuntu container with:
$ docker run -it ubuntu bash
Share images, automate workflows, and more with a free Docker ID:
https://hub.docker.com/
For more examples and ideas, visit:
https://docs.docker.com/get-started/
证明安装成功
- 查看镜像
docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
hello-world latest feb5d9fea6a5 7 months ago 13.3kB
-
卸载
- 1.卸载依赖
yum remove docker-ce docker-ce-cli containerd.io
- 删除资源
rm -rf /var/lib/docker
/var/lib/docker docker的默认工作路径
基础命令
帮助命令
-
docker version #查看docker 版本信息
-
docker info #查看docker系统信息，包括镜像和容器的数量
-
docker 命令 --help #帮助命令
镜像命令
查看
[root@CentOS ~]# docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
hello-world latest feb5d9fea6a5 6 months ago 13.3kB
# 解释
REPOSITORY 镜像的仓库源
TAG 镜像的标签
IMAGE ID 镜像的id
CREATED 镜像的创建时间
SIZE 镜像的大小
# 可选项
-a , --all # 列出所有镜像
-q , --quiet # 只显示镜像id
搜索
- 命令格式 ：docker search 名字
[root@CentOS ~]# docker search mysql
NAME DESCRIPTION STARS OFFICIAL AUTOMATED
mysql MySQL is a widely used, open-source relation… 12351 [OK]
mariadb MariaDB Server is a high performing open sou… 4754 [OK]
mysql/mysql-server Optimized MySQL Server Docker images. Create… 916 [OK]
#可选项
--filter=STARS=3000 #搜索出来的镜像就是STARS大于3000的
下载
-
命令格式：docker pull [名字] [:tag]
-
例如：docker pull mysql:5.7
[root@CentOS ~]# docker pull mysql
Using default tag: latest #如果不加 tag,默认就是latest
latest: Pulling from library/mysql
f003217c5aae: Pull complete #分层下载，docker iamge的核心 联合文件系统
65d94f01a09f: Pull complete
43d78aaa6078: Pull complete
a0f91ffbdf69: Pull complete
59ee9e07e12f: Pull complete
04d82978082c: Pull complete
70f46ebb971a: Pull complete
db6ea71d471d: Pull complete
c2920c795b25: Pull complete
26c3bdf75ff5: Pull complete
9ec1f1f78b0e: Pull complete
4607fa685ac6: Pull complete
Digest: sha256:1c75ba7716c6f73fc106dacedfdcf13f934ea8c161c8b3b3e4618bcd5fbcf195 #签名
Status: Downloaded newer image for mysql:latest
docker.io/library/mysql:latest #真实地址
#等价与它
docker pull mysql
docker.io/library/mysql:latest
删除
- 命令格式：docker rmi 【名字或id】
[root@CentOS ~]# docker rmi -f 667ee8fb158e #删除指定镜像
[root@CentOS ~]# docker rmi -f 容器id 容器id 容器id #删除多个镜像
[root@CentOS ~]# docker rmi -f $(docker iamges -aq) #删除全部镜像
容器命令
- 说明：有了镜像才能创建容器，下载sentos系统测试
[root@CentOS ~]# docker pull centos
Using default tag: latest
latest: Pulling from library/centos
a1d0c7532777: Pull complete
Digest: sha256:a27fd8080b517143cbbbab9dfb7c8571c40d67d534bbdee55bd6c473f432b177
Status: Downloaded newer image for centos:latest
docker.io/library/centos:latest
新建容器并启动
- 命令格式：docker run [可选参数] iamge
#参数说明
--name="Name" 容器名字 用来区分容器
-d 后台方式运行
-it 使用交互方式运行，进入容器查看内容
-p 指定容器端口 -p 8080:8080
（1）-p ip:主机端口:容器端口 （2）-p 主机端口:容器端口（常用） （3）-p 容器端口
-P 随机指定端口
- 测试，创建启动并进入容器
[root@CentOS ~]# docker run -it centos /bin/bash
WARNING: IPv4 forwarding is disabled. Networking will not work.
[root@32c10aad935b /]# ls #查看容器内的centos，基础版本，很多命令是不完善！
bin dev etc home lib lib64 lost+found media mnt opt proc root run sbin srv sys tmp usr var
[root@6537606d468c /]# exit #从容器退回主机
exit
列出所有运行的容器
- 命令格式：docker ps
[root@CentOS ~]# docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
[root@CentOS ~]# docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
6537606d468c centos "/bin/bash" 5 minutes ago Exited (0) About a minute ago objective_lamport
32c10aad935b centos "/bin/bash" 6 minutes ago Exited (127) 5 minutes ago amazing_dirac
40553ff2206e centos "/bin/bash" 8 minutes ago Exited (0) 7 minutes ago infallible_wing
7bf792cc2597 hello-world "/hello" 9 days ago Exited (0) 9 days ago admiring_bhabha
#可选参数
None 列出当前正在运行的容器
-a 列出当前正在运行的容器+带出历史运行过的容器
-n=1 列出最近创建的一个容器
-n=? 列出最近创建的所有容器
-p 只显示容器的编号
退出容器
exit 直接容器停止并退出
ctrl+P+Q 容器不停止退出
删除容器
docker rm 容器id #删除指定的容器,不能删除正在运行的容器,如果要强制删除 rm -f
docker rm -f $(docker ps -aq) #删除所有容器
docker ps -a -q | xargs docker rm #删除所有容器
启动和停止容器
docker start 容器id #启动容器
docker restart 容器id #重启容器
docker stop 容器id #停止当前正在运行的容器
docker kill 容器id #强制停止当前容器
常用命令
后台启动容器
命令格式：docker run -d 镜像名
[root@CentOS ~]# docker run -d centos
WARNING: IPv4 forwarding is disabled. Networking will not work.
202527a0e38696d3173571bc6783b04bf28727c03f6fdda1f4cd675aa628f992
[root@CentOS ~]# docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
#问题：docker ps ,发现centos 停止了
#常见的坑，docker容器使用后台运行，就必须要有一个前台进程，docker发现没有应用，就会自动停止
查看日志
命令各式：docker logs [可选参数] [容器id]
#自己编写一段shell脚本
[root@CentOS ~]# docker run -d centos /bin/bash -c "while true;do echo yangxiaobin;sleep 1;done"
WARNING: IPv4 forwarding is disabled. Networking will not work.
27fd2b95e71e3bd1290167c7566e7d40138d75e026a94ca613194f560e59b5f1
[root@CentOS ~]# docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
27fd2b95e71e centos "/bin/bash -c 'while…" About a minute ago Up About a minute festive_shirley
#可选参数
-tf #显示日志
--tial 数字 #显示日志条数
查看容器中进程信息
命令格式：docker top 容器id
[root@CentOS ~]# docker top d8f1b58c06fc
UID PID PPID C STIME TTY TIME CMD
root 25925 25906 0 01:17 pts/0 00:00:00 /bin/bash
查看镜像元数据
命令格式：docker inspect 镜像id
[root@CentOS ~]# docker inspect centos
[
{
"Id": "sha256:5d0da3dc976460b72c77d94c8a1ad043720b0416bfc16c52c45d4847e53fadb6",
"RepoTags": [
"centos:latest"
],
"RepoDigests": [
"centos@sha256:a27fd8080b517143cbbbab9dfb7c8571c40d67d534bbdee55bd6c473f432b177"
],
"Parent": "",
"Comment": "",
"Created": "2021-09-15T18:20:05.184694267Z",
"Container": "9bf8a9e2ddff4c0d76a587c40239679f29c863a967f23abf7a5babb6c2121bf1",
"ContainerConfig": {
"Hostname": "9bf8a9e2ddff",
"Domainname": "",
"User": "",
"AttachStdin": false,
"AttachStdout": false,
"AttachStderr": false,
"Tty": false,
"OpenStdin": false,
"StdinOnce": false,
"Env": [
"PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
],
"Cmd": [
"/bin/sh",
"-c",
"#(nop) ",
"CMD [\"/bin/bash\"]"
],
"Image": "sha256:f5b050f177fd426be8fe998a8ecf3fb1858d7e26dff4080b29a327d1bd5ba422",
"Volumes": null,
"WorkingDir": "",
"Entrypoint": null,
"OnBuild": null,
"Labels": {
"org.label-schema.build-date": "20210915",
"org.label-schema.license": "GPLv2",
"org.label-schema.name": "CentOS Base Image",
"org.label-schema.schema-version": "1.0",
"org.label-schema.vendor": "CentOS"
}
},
"DockerVersion": "20.10.7",
"Author": "",
"Config": {
"Hostname": "",
"Domainname": "",
"User": "",
"AttachStdin": false,
"AttachStdout": false,
"AttachStderr": false,
"Tty": false,
"OpenStdin": false,
"StdinOnce": false,
"Env": [
"PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
],
"Cmd": [
"/bin/bash"
],
"Image": "sha256:f5b050f177fd426be8fe998a8ecf3fb1858d7e26dff4080b29a327d1bd5ba422",
"Volumes": null,
"WorkingDir": "",
"Entrypoint": null,
"OnBuild": null,
"Labels": {
"org.label-schema.build-date": "20210915",
"org.label-schema.license": "GPLv2",
"org.label-schema.name": "CentOS Base Image",
"org.label-schema.schema-version": "1.0",
"org.label-schema.vendor": "CentOS"
}
},
"Architecture": "amd64",
"Os": "linux",
"Size": 231268856,
"VirtualSize": 231268856,
"GraphDriver": {
"Data": {
"MergedDir": "/var/lib/docker/overlay2/9170879ea41e2400b308a75ec2f104b39325453732d908e87ad4775d16370c25/merged",
"UpperDir": "/var/lib/docker/overlay2/9170879ea41e2400b308a75ec2f104b39325453732d908e87ad4775d16370c25/diff",
"WorkDir": "/var/lib/docker/overlay2/9170879ea41e2400b308a75ec2f104b39325453732d908e87ad4775d16370c25/work"
},
"Name": "overlay2"
},
"RootFS": {
"Type": "layers",
"Layers": [
"sha256:74ddd0ec08fa43d09f32636ba91a0a3053b02cb4627c35051aff89f853606b59"
]
},
"Metadata": {
"LastTagTime": "0001-01-01T00:00:00Z"
}
}
]
进入当前正在运行的容器
我们通常容器都是使用后台方式运行的，需要进入容器，修改一些配置
- 方法一：docker exec -it 容器id
[root@CentOS ~]# docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
d8f1b58c06fc centos "/bin/bash" 7 minutes ago Up 7 minutes crazy_payne
[root@CentOS ~]# docker exec -it d8f1b58c06fc /bin/bash
[root@d8f1b58c06fc /]# ls
bin dev etc home lib lib64 lost+found media mnt opt proc root run sbin srv sys tmp usr var
[root@d8f1b58c06fc /]# ps -ef
UID PID PPID C STIME TTY TIME CMD
root 1 0 0 05:17 pts/0 00:00:00 /bin/bash
root 15 0 0 05:25 pts/1 00:00:00 /bin/bash
root 30 15 0 05:25 pts/1 00:00:00 ps -ef
- 方法二 ：docker attach 容器id
[root@d8f1b58c06fc /]# docker attach d8f1b58c06fc
bash: docker: command not found #正在执行当前的代码…
-
docker exec # 进入容器后开启一个新的终端，可以在里面操作（常用）
docker attach # 进入容器正在执行的终端，不会启动新的进程
从容器内拷贝文件到主机上
命令格式：docker cp 容器id：容器路径 目的主机路径
#查看当前主机目录
[root@CentOS home]# ls
centos
#进入容器内部
[root@CentOS home]# docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
d8f1b58c06fc centos "/bin/bash" 20 minutes ago Up 20 minutes crazy_payne
[root@CentOS home]# docker attach d8f1b58c06fc
[root@d8f1b58c06fc /]#
#查看并创建文件
[root@d8f1b58c06fc /]# cd /home
[root@d8f1b58c06fc home]# ls
[root@d8f1b58c06fc home]# touch yangxiaobin.txt
[root@d8f1b58c06fc home]# exit
exit
[root@CentOS home]# docker ps #查看正在运行的容器
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
[root@CentOS home]# docker ps -a #查看历史运行过的容器
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
d8f1b58c06fc centos "/bin/bash" 25 minutes ago Exited (0) 27 seconds ago crazy_payne
#将文件拷贝出来主机上
[root@CentOS home]# docker cp d8f1b58c06fc:/home/yangxiaobin.txt /home
[root@CentOS home]# ls
centos yangxiaobin.txt
#拷贝是一个手动过程，使用 -v 卷技术，可以实现自动同步 /home /home
commit提交镜像
docker commit 提交容器称为一个新的副本
docker commit -m='提交的描述信息' -a='作者' 容器id 目标镜像名:[tag]
docker commit -m='info' -a='yangxiaobin' c6e5d001104a centos:2.0
容器数据卷
容器之间数据共享，Docker容器产生的数据，同步到本地
目录的挂载，将容器目录挂载到Linux上面
容器间也可以数据共享
方式一：直接使用命令 -v
docker -it -v 主机目录:容器内目录
#测试
docker run -it -v /home/ceshi:/home centos /bin/bash
docker inspect 96243a8f4398
两边互相修改数据都可进行数据更新
部署MySQL
#下载
docker pull mysql
#启动
#官方测试 docker run --name some-mysql -v /my/custom:/etc/mysql/conf.d -e MYSQL_ROOT_PASSWORD=my-secret-pw -d mysql:tag
docker run -d -p 3310:3306 -v /home/docker/mysql/conf:/etc/mysql/conf.d -v /home/docker/mysql/data/:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=123456 --name mysql01 mysql
-d 后台运行
-e 环境配置
--name 容器名字
# 启动成功之后使用本地sqlyog来连接测试 3310
部署nginx
网页无法获取尝试进入容器开启nginx服务
service nginx start
实践
构建自定义镜像
commit
docker commit -a="作者" -m="提交的描述信息" 容器id 目标镜像名:版本
dockerfile
mkdir nginx-image
cd nginx-image/
wget http://nginx.org/download/nginx-1.18.0.tar.gz
mkdir wwwroot
vi wwwroot/index.html
<html>
<head>
<title>Nginx</title>
</head>
<body>
<span>Test Nginx Image</span>
</body>
</html>
创建dockerfile
FROM centos:centos7
MAINTAINER "yangxiaobin"
ADD nginx-1.18.0.tar.gz /opt
WORKDIR /opt/nginx-1.18.0
RUN yum -y install gcc pcre-devel openssl-devel make \
&& groupadd www-data && useradd -s /sbin/nologin -g www-data www-data \
&& ./configure \
--prefix=/usr/local/nginx \
--conf-path=/etc/nginx/nginx.conf \
--user=www-data \
--group=www-data \
--with-pcre \
--with-http_v2_module \
--with-http_ssl_module \
--with-http_realip_module \
--with-http_addition_module \
--with-http_sub_module \
--with-http_dav_module \
--with-http_flv_module \
--with-http_mp4_module \
--with-http_gunzip_module \
--with-http_gzip_static_module \
--with-http_random_index_module \
--with-http_secure_link_module \
--with-http_stub_status_module \
--with-http_auth_request_module \
--with-mail \
--with-mail_ssl_module \
--with-file-aio \
--with-http_v2_module \
--with-threads \
--with-stream \
--with-stream_ssl_module && make && make install
VOLUME ["/usr/local/nginx/html"]
ENV PATH /usr/local/nginx/sbin:$PATH
EXPOSE 80
ENTRYPOINT ["nginx"]
CMD ["-g","daemon off;"]
docker build ./ -t nginx:v2
检查
容器操作
复制文件到容器
echo "数据" > index.html
docker cp index.html mynginx:/usr/share/nginx/html
打包容器成tar文件
docker export -o mynginx.tar mynginx
将tar文件新建一个镜像
docker import mynginx.tar nginx:v1.0
查看容器与宿主机端口映射
docker port mynginx
资源管理
限制容器内存
docker run -itd --name=busybox -m 512m busybox
限制CPU份额
docker run -itd -c 1000 --name test01 progrium/stress --cpu 4
#查看
top
占满一颗CPU
docker run -itd --cpuset-cpus=1 --name cputest agileek/cpuset-test
磁盘I/O
-
读写带宽
docker run -itd --name centos01 --blkio-weight=800 centos -
读写效率
docker run -itd --name busybox --device-read-bps /dev/sda:30MB busybox
数据卷
创建数据卷
docker run -itd --name=mynginx -p 80:80 -v myweb:/usr/share/nginx/html nginx
docker inspect mynginx
"Mounts":[]
创建数据卷容器，容器的数据共享
创建数据卷
docker run -it --name=cintainer -v /share:/mnt centos:7
cd /mnt/
echo mycentos > test.txt
exit
cd /share/
ls
cat test.txt
数据共享
docker run -it --name=test1 --volumes-from container centos:7
cd /mnt
ls
cat test.txt
删除container容器，test1容器与宿主机数据还在
备份和回复
创建数据卷
docker run -it --name=data-volume -v /var/volume centos:7
ls
echo hello > /var/volume/test.txt
exit
备份
docker run --rm --volumes-from data-volume -v /root/backup:/backup centos:7 \
tar cvf /backup/backup.tar /var/volume
ls
cd backup/
ls
tar -xf backup.tar
ls
cat var/volume/test.txt
删除容器备份文件后恢复
docker run -it --rm --volumes-from data-volume -v /root/backup:/backup centos:7 \
tar xvf /backup/backup.tar -C
docker网络
[root@host1~]# vi /etc/docker/daemon.json
{
"registry-mirrors": ["https://x3n9jrcg.mirror.aliyuncs.com"],
"bip": "192.168.2.1/24"
}
[root@host1~]# systemctl restart docker
-
使用同样的方法，调整host2主机上的docker网络，将docker0的IP地址调整为192.168.3.1/24
-
添加互通路由
[root@host1~]# ip route add 192.168.3.0/24 via 192.168.1.8 [root@host1~]# route –n [root@host2~]# ip route add 192.168.2.0/24 via 192.168.1.7 [root@host2~]#route -n -
配置防火墙的NAT规则
[root@host1~]# iptables -t nat -I PREROUTING -s 192.168.2.0/24 -d 192.168.3.0/24 -j DNAT --to 192.168.1.8[root@host2~]# iptables -t nat -I PREROUTING -s 192.168.3.0/24 -d 192.168.2.0/24 -j DNAT --to 192.168.1.7
Flannel网络
[root@host1~]# yum -y install etcd flannel
配置etcd
[root@host1~]# vi /etc/etcd/etcd.conf
ETCD_DATA_DIR="/var/lib/etcd/default.etcd"
ETCD_LISTEN_CLIENT_URLS="http://0.0.0.0:2379"
ETCD_NAME="default"
ETCD_ADVERTISE_CLIENT_URLS="http://0.0.0.0:2379"
# 启动 etcd 服务
[root@host1~]# systemctl start etcd && systemctl enable etcd
# flannel 配置
[root@host1~]# vi /etc/sysconfig/flanneld
FLANNEL_ETCD_ENDPOINTS="http://192.168.100.10:2379"
FLANNEL_ETCD_PREFIX="/atomic.io/network"
# 在 etcd 中添加网段
[root@host1~]# etcdctl mk /atomic.io/network/config '{"Network":"172.20.0.0/16"}'
# 查看etcd是否生效
[root@host1~]# etcdctl get /atomic.io/network/config
{"Network":"172.20.0.0/16"}
# 启动 flannel 服务
[root@host1~]# systemctl start flanneld && systemctl enable flanneld
[root@host2~]# yum -y install flannel
# flannel 配置
[root@host2~]#vi /etc/sysconfig/flanneld
FLANNEL_ETCD_ENDPOINTS="http://192.168.100.10:2379"
FLANNEL_ETCD_PREFIX="/atomic.io/network"
# 启动 flannel 服务
[root@host2~]# systemctl start flanneld && systemctl enable flanneld
-
配置docker使用
[root@host1~]# cat /run/flannel/subnet.env FLANNEL_NETWORK=172.20.0.0/16 FLANNEL_SUBNET=172.20.24.1/24 FLANNEL_MTU=1472 FLANNEL_IPMASQ=false [root@host1~]# vi /etc/docker/daemon.json { "registry-mirrors": ["https://x3n9jrcg.mirror.aliyuncs.com"], "bip": "172.20.24.1/24", "mtu": 1472 } [root@host2~]# cat /run/flannel/subnet.env FLANNEL_NETWORK=172.20.0.0/16 FLANNEL_SUBNET=172.20.32.1/24 FLANNEL_MTU=1472 FLANNEL_IPMASQ=false [root@host2~]# vi /etc/docker/daemon.json { "registry-mirrors": ["https://x3n9jrcg.mirror.aliyuncs.com"], "bip": "172.20.32.1/24", "mtu": 1472 } 两个主机均重启 docker服务、修改防火墙规则 # systemctl restart docker #iptables -P INPUT ACCEPT #iptables -P FORWARD ACCEPT #iptables -F
私有仓库
-
生成证书
mkdir -p /opt/docker/registry/certs openssl req -newkey rsa:4096 -nodes -sha256 -keyout /opt/docker/registry/certs/domain.key -x509 -days 365 -out /opt/docker/registry/certs/domain.crt 解析域名 vi /etc/hosts cat /etc/hosts 127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4 ::1 localhost localhost.localdomain localhost6 localhost6.localdomain6 192.168.100.10 registry.docker.com mkdir /etc/docker/certs.d cd /etc/docker/certs.d/ mkdir registry.docker.com:5000 cp -r -p /opt/docker/registry/certs/domain.crt /etc/docker/certs.d/registry.docker.com:5000/ca.crt ls registry.docker.com\:5000/ [root@host1 ~]# vi /etc/docker/daemon.json [root@host1 ~]# cat /etc/docker/daemon.json { "registry-mirrors": ["https://x3n9jrcg.mirror.aliyuncs.com"], "insecure-registries": ["registry.docker.com:5000"] } systemctl daemon-reload systemctl restart docker mkdir /opt/docker/registry/auth yum install -y httpd htpasswd -Bbn yxb yxbpassword > /opt/docker/registry/auth/htpasswd cd /opt/docker/registry/auth/ ls docker run -d -it \ --name registry-auth \ -p 5000:5000 \ -v /opt/docker/registry/auth/:/auth \ -e "REGISTRY_AUTH=htpasswd" \ -e "REGISTRY_AUTH_HTPASSWD_REALM=Registry Realm" \ -e REGISTRY_AUTH_HTPASSWD_PATH=/auth/htpasswd \ -v /opt/docker/registry/certs:/certs \ -e REGISTRY_HTTP_TLS_CERTIFICATE=/certs/domain.crt \ -e REGISTRY_HTTP_TLS_KEY=/certs/domain.key registry
可视化私有仓库
[root@host1 ~]# vi /etc/docker/daemon.json
[root@host1 ~]# cat /etc/docker/daemon.json
{
"registry-mirrors": ["https://x3n9jrcg.mirror.aliyuncs.com"],
"insecure-registries": ["192.168.100.10:5000"]
}
docker pull registry
docker run -itd -p 5000:5000 \
--restart=always \
--name registry registry
docker pull hyper/docker-registry-web
docker run -itd \
--restart=always \
-p 8080:8080 \
--name registry-web \
-- link registry \
-e REGISTRY_URL=http://192.168.100.10:5000/v2 \
-e REGISTRY_NAME=192.168.100.10:5000 hyper/docker-registry-web
#测试
docker pull centos
docker tag centos 192.168.100.10:5000/centos
docker push 192.168.100.10:5000/centos
可视化管理容器
vi /usr/local/bin/scope
#!/bin/sh
set -eu
ARGS="$*"
SCRIPT_VERSION="1.13.2"
if [ "$SCRIPT_VERSION" = "(unreleased version)" ]; then
IMAGE_VERSION=latest
else
IMAGE_VERSION="$SCRIPT_VERSION"
fi
IMAGE_VERSION=${VERSION:-$IMAGE_VERSION}
DOCKERHUB_USER=${DOCKERHUB_USER:-weaveworks}
SCOPE_IMAGE_NAME="$DOCKERHUB_USER/scope"
SCOPE_IMAGE="$SCOPE_IMAGE_NAME:$IMAGE_VERSION"
# Careful: it's easy to operate on (e.g. stop) the wrong scope instance
# when SCOPE{_APP,}_CONTAINER_NAME values differ between runs. Handle
# with care.
SCOPE_CONTAINER_NAME="${SCOPE_CONTAINER_NAME:-weavescope}"
SCOPE_APP_CONTAINER_NAME="${SCOPE_APP_CONTAINER_NAME:-weavescope-app}"
IP_REGEXP="[0-9]{1,3}\\.[0-9]{1,3}\\.[0-9]{1,3}\\.[0-9]{1,3}"
IP_ADDR_CMD="find /sys/class/net -type l | xargs -n1 basename | grep -vE 'docker|veth|lo' | \
xargs -n1 ip addr show | grep inet | awk '{ print \$2 }' | grep -oE '$IP_REGEXP'"
LISTENING_IP_ADDR_CMD="for I in \$( $IP_ADDR_CMD ); do if curl -m 1 -s \${I}:4040 > /dev/null ; then echo \${I}; fi; done"
WEAVESCOPE_DOCKER_ARGS=${WEAVESCOPE_DOCKER_ARGS:-}
# When docker daemon is running with User Namespace enabled, this tool will run into errors:
# "Privileged mode is incompatible with user namespaces" for `docker run --privileged`
# "Cannot share the host's network namespace when user namespaces are enabled" for `docker run --net=host`
# To avoid above errors, use `--userns=host` option to let container use host User Namespace.
# This option(saved in $USERNS_HOST) will be inserted ONLY IF docker support `--userns` option.
USERNS_HOST=""
docker run --help | grep -q -- --userns && USERNS_HOST="--userns=host"
usage() {
name=$(basename "$0")
cat >&2 <<-EOF
Usage:
$name launch {OPTIONS} {PEERS} - Launch Scope
$name stop - Stop Scope
$name command - Print the docker command used to start Scope
$name help - Print usage info
$name version - Print version info
PEERS are of the form HOST[:PORT]
HOST may be an ip or hostname.
PORT defaults to 4040.
Launch options:
EOF
docker run --rm --entrypoint=/home/weave/scope "$SCOPE_IMAGE" -h >&2
}
usage_and_die() {
usage
exit 1
}
[ $# -gt 0 ] || usage_and_die
COMMAND=$1
shift 1
check_docker_access() {
# Extract socket path
DOCKER_SOCK_FILE=""
if [ -z "${DOCKER_HOST+x}" ]; then
DOCKER_SOCK_FILE="/var/run/docker.sock"
else
WITHOUT_PREFIX="${DOCKER_HOST#unix://}"
if [ "$WITHOUT_PREFIX" != "$DOCKER_HOST" ]; then
DOCKER_SOCK_FILE="$WITHOUT_PREFIX"
fi
fi
# shellcheck disable=SC2166
if [ \( -n "$DOCKER_SOCK_FILE" \) -a \( ! -w "$DOCKER_SOCK_FILE" \) ]; then
echo "ERROR: cannot write to docker socket: $DOCKER_SOCK_FILE" >&2
echo "change socket permissions or try using sudo" >&2
exit 1
fi
}
# - The image embeds the weave script & Docker 1.13.1 client (mimicking a 1.10 client)
# - Weave needs 1.10.0 now (image pulling changes)
MIN_DOCKER_VERSION=1.10.0
check_docker_version() {
if ! DOCKER_VERSION=$(docker -v | sed -n 's%^Docker version \([0-9]\{1,\}\.[0-9]\{1,\}\.[0-9]\{1,\}\).*$%\1%p') \
|| [ -z "$DOCKER_VERSION" ]; then
echo "ERROR: Unable to parse docker version" >&2
exit 1
fi
DOCKER_VERSION_MAJOR=$(echo "$DOCKER_VERSION" | cut -d. -f 1)
DOCKER_VERSION_MINOR=$(echo "$DOCKER_VERSION" | cut -d. -f 2)
DOCKER_VERSION_PATCH=$(echo "$DOCKER_VERSION" | cut -d. -f 3)
MIN_DOCKER_VERSION_MAJOR=$(echo "$MIN_DOCKER_VERSION" | cut -d. -f 1)
MIN_DOCKER_VERSION_MINOR=$(echo "$MIN_DOCKER_VERSION" | cut -d. -f 2)
MIN_DOCKER_VERSION_PATCH=$(echo "$MIN_DOCKER_VERSION" | cut -d. -f 3)
# shellcheck disable=SC2166
if [ \( "$DOCKER_VERSION_MAJOR" -lt "$MIN_DOCKER_VERSION_MAJOR" \) -o \
\( "$DOCKER_VERSION_MAJOR" -eq "$MIN_DOCKER_VERSION_MAJOR" -a \
\( "$DOCKER_VERSION_MINOR" -lt "$MIN_DOCKER_VERSION_MINOR" -o \
\( "$DOCKER_VERSION_MINOR" -eq "$MIN_DOCKER_VERSION_MINOR" -a \
\( "$DOCKER_VERSION_PATCH" -lt "$MIN_DOCKER_VERSION_PATCH" \) \) \) \) ]; then
echo "ERROR: scope requires Docker version $MIN_DOCKER_VERSION or later; you are running $DOCKER_VERSION" >&2
exit 1
fi
}
check_probe_only() {
echo "${ARGS}" | grep -q -E -e "--no-app|--service-token|--probe-only"
}
check_listen_address_arg() {
echo "${ARGS}" | grep -q -E -e "--app\\.http\\.address"
}
check_docker_for_mac() {
[ "$(uname)" = "Darwin" ] \
&& [ -S /var/run/docker.sock ] \
&& [ ! "${DOCKER_HOST+x}" = x ] \
&& [ "${HOME+x}" = x ] \
&& [ -d "${HOME}/Library/Containers/com.docker.docker/Data" ]
}
# Check that a container named $1 with image $2 is not running
check_not_running() {
case $(docker inspect --format='{{.State.Running}} {{.Config.Image}}' "$1" 2>/dev/null) in
"true $2")
echo "$1 is already running." >&2
exit 1
;;
"true $2:"*)
echo "$1 is already running." >&2
exit 1
;;
"false $2")
docker rm "$1" >/dev/null
;;
"false $2:"*)
docker rm "$1" >/dev/null
;;
true*)
echo "Found another running container named '$1'. Aborting." >&2
exit 1
;;
false*)
echo "Found another container named '$1'. Aborting." >&2
exit 1
;;
esac
}
check_plugins_dir() {
# If plugins dir exists for Docker containers then we will mount it
# (the context for Docker might be different to that for this script, e.g. when using Docker for Mac)
if docker run $USERNS_HOST --rm --entrypoint=/bin/sh \
-v /var/run:/var/run \
"$SCOPE_IMAGE" -c "test -d /var/run/scope/plugins"; then
PLUGINS_DIR_EXISTS=true
fi
}
docker_args() {
echo --privileged $USERNS_HOST --net=host --pid=host \
-v /var/run/docker.sock:/var/run/docker.sock \
-v /sys/kernel/debug:/sys/kernel/debug \
-e CHECKPOINT_DISABLE
# shellcheck disable=SC2039
[ -n "${PLUGINS_DIR_EXISTS:-}" ] && echo -v /var/run/scope/plugins:/var/run/scope/plugins
}
launch_command() {
# shellcheck disable=SC2046,SC2086
echo docker run -d --name="$SCOPE_CONTAINER_NAME" $(docker_args) \
$WEAVESCOPE_DOCKER_ARGS "$SCOPE_IMAGE" --probe.docker=true
}
launch_docker4mac_app_command() {
# shellcheck disable=SC2086
echo docker run -d --name="$SCOPE_APP_CONTAINER_NAME" \
-e CHECKPOINT_DISABLE \
-p 0.0.0.0:4040:4040 \
$WEAVESCOPE_DOCKER_ARGS "$SCOPE_IMAGE" --no-probe
}
launch() {
check_not_running "$SCOPE_CONTAINER_NAME" "$SCOPE_IMAGE_NAME"
docker rm -f "$SCOPE_CONTAINER_NAME" >/dev/null 2>&1 || true
$(launch_command) "$@"
echo "Scope probe started"
}
print_app_endpoints() {
HOST_SUFFIX=""
if [ -n "${DOCKER_HOST+x}" ]; then
DOCKER_HOSTNAME=$(run_in_scope_container hostname)
HOST_SUFFIX=" of host $DOCKER_HOSTNAME"
fi
echo "Weave Scope is listening at the following URL(s)${HOST_SUFFIX}:" >&2
for ip in "$@"; do
echo " * http://$ip:4040/" >&2
done
}
dry_run() {
# Do a dry run of scope in the foreground, so it can parse args etc
# avoiding the entrypoint script in the process.
# shellcheck disable=SC2046
docker run --rm --entrypoint=/home/weave/scope $(docker_args) "$SCOPE_IMAGE" --dry-run "$@"
}
run_in_scope_container() {
docker run --rm $USERNS_HOST --net=host --entrypoint /bin/sh "$SCOPE_IMAGE" -c "$1"
}
# Wait for the scope app to start listening on localhost:4040
wait_for_http() {
for seconds in $(seq 5); do
if run_in_scope_container "curl -m 1 -s localhost:4040" >/dev/null; then
break
fi
sleep 1
done
if [ "$seconds" -eq 5 ]; then
echo "The Scope App is not responding. Consult the container logs for further details."
exit 1
fi
}
check_docker_access
check_docker_version
case "$COMMAND" in
command)
# Most systems should have printf, but the %q specifier isn't mandated by posix
# and can't be guaranteed. Since this is mainly a cosmetic output and the alternative
# is not making any attempt to do escaping at all, we might as well try.
# shellcheck disable=SC2039
quoted=$(printf '%q ' "$@" 2>/dev/null || true)
# printf %q behaves oddly with zero args (it acts as though it received one empty arg)
# so we ignore that case.
if [ -z "$quoted" ] || [ $# -eq 0 ]; then
quoted="$*"
fi
echo "$(launch_command) $quoted"
;;
version)
docker run --rm --entrypoint=/home/weave/scope "$SCOPE_IMAGE" --mode=version
;;
-h | help | -help | --help)
usage
;;
launch)
dry_run "$@"
check_plugins_dir
if check_docker_for_mac; then
if check_probe_only; then
launch "$@"
exit
fi
# Docker for Mac (as of beta9) does not ship vmnet driver and
# thereby only access container ports via a tunnel, preventing
# access to host ports of the VM.
# - https://github.com/weaveworks/scope/issues/1411
# - https://forums.docker.com/t/ports-in-host-network-namespace-are-not-accessible/10789
if check_listen_address_arg; then
echo "--app.http.address argument not supported on Docker for Mac" >&2
exit 1
fi
check_not_running "$SCOPE_APP_CONTAINER_NAME" "$SCOPE_IMAGE_NAME"
check_not_running "$SCOPE_CONTAINER_NAME" "$SCOPE_IMAGE_NAME"
docker rm -f "$SCOPE_APP_CONTAINER_NAME" >/dev/null 2>&1 || true
CONTAINER=$($(launch_docker4mac_app_command) "$@")
echo "Scope probe started"
app_ip=$(docker inspect -f '{{.NetworkSettings.IPAddress}}' "${CONTAINER}")
docker rm -f "$SCOPE_CONTAINER_NAME" >/dev/null 2>&1 || true
# shellcheck disable=SC2091
CONTAINER=$($(launch_command) --no-app "$@" "${app_ip}:4040")
print_app_endpoints "localhost"
exit
fi
launch "$@"
if ! check_probe_only; then
if check_listen_address_arg; then
echo "Weave Scope is listening at the address specified with --app.http.address" >&2
else
wait_for_http
IP_ADDRS=$(run_in_scope_container "$LISTENING_IP_ADDR_CMD")
# shellcheck disable=SC2086
print_app_endpoints $IP_ADDRS
fi
fi
;;
stop)
[ $# -eq 0 ] || usage_and_die
if docker inspect "$SCOPE_CONTAINER_NAME" >/dev/null 2>&1; then
docker stop "$SCOPE_CONTAINER_NAME" >/dev/null
fi
if check_docker_for_mac; then
if docker inspect "$SCOPE_APP_CONTAINER_NAME" >/dev/null 2>&1; then
docker stop "$SCOPE_APP_CONTAINER_NAME" >/dev/null
fi
fi
;;
*)
echo "Unknown scope command '$COMMAND'" >&2
usage_and_die
;;
esac
给权限
chmod a+x /usr/local/bin/scope
scope launch
码道开发者社区，聚焦华为云码道 CodeArts 代码智能体，沉淀 Agent、Skill、鸿蒙开发实战内容，供开发者查阅资料、交流技术、分享工程实践
更多推荐
23
0- 0
已为社区贡献3条内容
所有评论(0)
